18 years one stop design and manufacture 4 layer circuit board copper flexible RF circuit board for Led lighting
- $0.20 / 1 - 499 pieces
$0.15 / 500 - 4999 pieces
$0.10 / >=5000 pieces - 1 piece
- Ucreate Pcb Co., Ltd.
- Guangdong, China
- Mr
PRODUCT DETAIL
| Silkscreen Color: | Black | place of origin; place of origin: | Guangdong, China |
| Copper Thickness: | 1.5 oz | Plate thickness: | 1.6 |
| pack: | vacuum bag | Packaging Preview: | |
| minute. Line width: | 0.05mm | Certificate: | ISO9001/IATF16949/ISO14001/ROHS |
| Surface treatment: | Shen Jin | minute. Hole size: | 0.1mm |
| port: | Shenzhen | Solder mask: | blue |
| minute. Line spacing: | 0.05mm | Supply capacity: | 40000 square meters/month |
| Minimum order quantity: | 1 | Board size: | 260.35*151.13mm |
| PCB test: | Electronic Test Fixtures | payment terms: | L/C,Western Union,D/P,D/A,T/T,MoneyGram |
| brand: | create | Substrate: | RF-4 |
| Test service: | function test | application: | Electronic equipment |
| Packaging Details: | Inner packaging: vacuum packaging Outer packaging: standard carton packaging | Serve: | One-stop service |
| type: | Rigid-flex board | model: | UCT-PCBR01 |
| ID: | accept |
Product Description
18 years one-stop design and manufacture of 4-layer circuit boards for LEDs Copper flexible RF PCBsPCB Board Manufacturing Detail Specification | ||
layer | 1-30 layers | |
Human Development Index | 1+N+1&2+N+2&3+N+3 | |
Material | FR4, CEM3, Rogers, High TG, high frequency board, aluminum, copper, ceramic, etc. | |
Finished inner/outer copper thickness | 0.5-6oz, normal 1oz | |
Finished plate thickness | 0.2-7.0mm, conventional 1.6mm | |
Minimum through hole size | 0.15mm | |
Maximum panel size | 800*1200mm | |
Minimum panel size | 5*5mm | |
finger (gold) | 1-50U'', ordinary 30U'' | |
Solder mask color | white, black, green, red, blue, yellow, etc. | |
silk screen | white, black, etc. | |
Screen printing minimum line width | 0.1mm | |
Minimum trace/gap | 3/3mil | |
surface treatment | Spray tin, spray tin, lead-free, immersion gold, OSP, immersion gold, immersion tin, immersion silver, hard gold, flash gold | |
controlled impedance | +/-5% | |
Pore blocking ability | 0.2-0.8mm | |
Introduction to the Outline | Routing/Punching/V-cut/Stamp Holes | |
cut | V score | |
Certification | UL USA, UL Canada, ROHS, ISO13485, ISO9001, ISO14001, IATF 16949 | |
PCBA process
• Equipped with SPI machine and AOI inspector • 01005 components, fine pitch and high count BGA, Package on Package (POP) • Chip on Board, Fiber Optic, RF Microelectronics, Crimp Connectors • Hybrid Process (SnPb and Pb-Free) ), lead through-hole, wave and selective soldering, double- and single-sided reflow, wide body and backplane rapid turn prototyping assembly, RoHS compliance certification, conformal and parylene coatings, laser Marking • Using the latest SPI, AOI, flying probe and X-ray equipment • Comprehensive electrical testing and test system development for Boundary Scan, In-Circuit Test (ICT), Functional Test and Burn-in Test (BIT)
Our advantage
our service
Ucreate has the capability to manufacture pcbs from basic single sided to 30-layer multilayer boards, we provide one-stop service including pcb layout, fabrication, assembly, component sourcing and functional testing.
100% QC before shipment, on time delivery.
