2/3/4/ various size flute single blade pvc cutting tool Professional CNC cutter
- $1.10 / >=5 pieces
- 5 pieces
- Zhuzhou OBT Carbide Tools Co., Ltd.
- Hunan, China
- Ms julie ou
| particle: | 0.6um | Human Resources Committee: | 45/55/65 |
| Origin: | Hunan, China | Supply capacity: | 1,000,000 pieces of carbide end mills per month |
| type: | end mill | Packaging Details: | 2/3/4/ Flute various sizes single edge pvc cutter CNC professional milling cutter Packing: 1pc/plastic box 50pcs/bubble bag 100pcs/carton |
| port: | Shenzhen end mill carbide | Overall length: | 50-200mm, 50-150mm |
| brand: | Beta | flute: | 2-6 flutes |
| Applies to: | Copper. Cast iron. Carbon steel. Die steel | Shipping Details: | 10-20 days |
| coating: | aluminum nitride | Material: | carbide |
| surface: | high polish | product name: | end mill |
| product name: | Tungsten carbide end mill | payment terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal |
| application: | coal mining | diameter: | 0.1mm-20mm, 0.5-20mm |
| model: | HRC55 |
2/3/4/ Flute various sizes single edge pvc cutting tool CNC professional milling cutter
Tool material composition:
1. Physical properties:
a. Hardness greater than or equal to 94 HRA;
b. Density greater than or equal to 14.6g/cm³;
c. TRS greater than or equal to 4100 N/mm²;
d. No ETA phase condition;
e. Free from contamination by other materials;
F. Porosity = A00/B00/C00;
g. The particle size is uniform. The grain size cannot be larger than the specified value.
H. Chromium carbide grain growth inhibitor only.
2. All production tools and coatings adopt German and Swiss processing equipment;
coating:
General purpose high performance coating AlCrSiN
Features and functions
1, Due to the application of various materials, the cutting speed and feed are significantly improved, and the productivity is improved. Significantly increased productivity.
2. The special structural design achieves a good balance between toughness, thermal shock stability and residual stress.
Text description:
The structure of the Iphone 8 is made of 316L stainless steel. This material is more difficult to cut than 304 stainless steel. In particular, Apple's suppliers use MIM to process small parts, and the previous end mills can no longer meet their needs. Our team has adopted special ultra-fine grain tungsten carbide, special helix angle, special cutting edge design and nano AlCrSinN, the product has achieved perfect success and has been highly evaluated by FOXCNN and MiYa.
feature:
Suitable for rough milling, semi-finishing and finishing of stainless steel (<280HB).
It is specially designed for face milling with small depth/wide width, side milling with large depth/small width, shallow groove less than 0.3D.
Water soluble or oil based are the best cooling methods.
