48V/64V/72V 500W 600W 800W 1500w Electric Bicycle Electric Scooter Sine Wave Brushless Controller For Electric Bicycle Scooter BLDC Motor

48V/52V/60V/64V/72V 26-33A 500-650W 60°/120° Phase Angle Universal Brushless Controller

1. Button 3 gears 4 gears (generally not used)
2. Dedicated to differential motor (generally not used)
3. Self-study
4.3 speeds (low/medium/high speed)
5. Low brake
6. Single line LCD instrument
7. Hall LCD instrument
8. Pedal Assist (PAS)
9. Alarm power supply
10. Alarm signal
11. Cruise ship
12. Reverse
13. Hall
14. Throttle
15. Phase tachometer line
16. High brake
17. Electric lock
18. Battery
19. Motor wire

How to connect the controller?

1. Connect the motor wires (color to color)

2. Connect the battery wires (red: +, black: -)

3. Connect the throttle cable of the controller and the electric lock (if the throttle does not have an electric lock, connect the electric lock of the controller, if
The controller electric lock is 1 wire and can be connected to the battery+)

4. Connect the Hall wire (if the motor has no Hall wire, no connection is required)

5. Butt two self-learning lines, the wheels will move forward or backward.

(1. If the wheel is forward, separate the self-learning line.

2. If the wheel is reversed, separate the self-learning line. Dock the self-learning line again, if the wheel is forward, separate
self-taught line. )

6. Other functions can be connected as required.
