500kg/h corn peeling and degerming machine

PRODUCT DETAIL
capacity:500KG/Hbrand:Win sound
After-sales service provided:Free spare parts, on-site installation and commissioning training, on-site maintenance and repair services, online support, video technical supportusage:Food Industry Equipment
Supply capacity:100 units per monthplace of origin; place of origin:Henan, China
application:Corn Peelers and PolishersPackaging Details:1. We will pack with protective film inside and waterproof plastic outside. 2.Wooden packing is necessary if we send in less than one container. 3. The machine will be fixed in the container with wire rope. Make sure it arrives in good condition.
payment terms:L/C,D/A,D/P,T/T,Western Union,MoneyGramproduct name:500kg/h corn peeling and degerming machine
Model:NF280type:peeling machine
Warranty:1 yearApplicable industries:Manufacturing plants, farms, households, retail
port:Qingdao Port
Product Description

 500kg/h corn peeling and degerming machine:

1. For corn peeling, wheat peeling, rice peeling, sorghum peeling.
2. Suitable for peeling corn, wheat, sorghum and other small food processing plants.
Working principle and features:
Win Tone NF-280 500kg/h corn peeling and degerming machine mainly has the functions of corn peeling, wheat peeling, rice peeling and polishing. The machine is equipped with a 7.5W 380V motor, which can process 500kg of corn, wheat, sorghum and rice per hour.







working principle

Working principle of 500kg/h corn peeling and degerming machine:

The cleaned and unprocessed corn enters the peeling chamber of the NF-280 corn peeling machine through the feeding port for degermination. By controlling the feeding speed of the feeding port and the pressure of the pressure valve, the peeling chamber has a certain pressure. The machine extrudes, peels, degerms, removes impurities and polishes the material between the rotating roller and the screen. Under the action of pneumatics, the corn kernels and bran are automatically separated, and qualified corn kernels can be obtained. An efficient suction chamber is installed inside the machine to remove skin and impurities during the peeling process.











Features and Benefits

 Features of corn peeling and polishing machine:

1. The structure is simple, the processing and installation process is good, the volume is small, and the operation is convenient. The whole machine occupies less than one square meter and can be fixed only by installing pitch screws.
2, wheat, sorghum, rice peeling, polishing function.
3. Built-in high-efficiency air-selection dust-removing fan.
4. High yield and good effect.
The discharge port of the peeling chamber can precisely control the residence time of corn or wheat in the peeling chamber through the pressure valve to ensure effective friction with the alloy roller, so as to achieve better peeling effect.





Technical parameters of corn peeling and polishing machine:



Model
yield
(kg/hour)
strength
(kilowatt)
Rated voltage
(five)
Spindle speed (r/Min)
weight
(Kilogram)
Dimensions
(mm)
NF-280
corn peeling
500-600
7.5
380
1000-1200
180
1000x400x1200
peeled wheat
600-700
millet peeled
1000-1500
