ASTM a36 a53 Q235 Q345 and other angle steel angle steel standard dimensions

PRODUCT DETAIL
product name:Galvanized angle steeldelivery time:8-14 days
payment terms:Western Union, T/TOrigin:Shandong China
shape:equal or notapplication:Building construction, communication tower
technology:hot rolledProcessing services:Bending, welding, punching, cutting
surface:hot rolled blackbrand:to be determined
Alloy or not:is an alloyusage:building materials building materials
Package preview:pack:Standard Shipping Packing
length:6m-12m or as requiredKey words:Angle steel standard size
tolerant:±1%Invoicing:by actual weight
Supply capacity:1000 metric tons per monthMOQ:1 ton
Packaging Details:Standard seaworthy packaging, covered with woven bags and bundled.grade:Q195-Q420 series
thickness:3-24mmstandard:Aisi ASTM National Standard JIS
type:equal or notport:Qingdao Port Tianjin Port Shanghai Port
product name
Angle steel
grade
A36, S235jr, S275jr, S355jr, St37-2, SS400, Q235, Q345,
standard
ASTM, AISI, EN, DIN, JIS, GB
size
1.25#-25#
thickness
1-35mm
length
3-9m, 4-12m, 4-19m, 6-19, 6-15m or according to customer requirements
technology
hot rolled, galvanized, slotted
usage
building materials building materials
shape
equal or not
pack
Standard Shipping Packing
delivery conditions
FOB, CIF, CFR, EXW
payment terms
T/T 30% deposit and T/T 70% balance against the copy of B/L,
Irrevocable 100% L/C at sight.
delivery date
5-15 days after receiving the deposit
Product advantages
1. Over 10 years high quality with competitive price
2. BV and ISO certificates can be provided to ensure the quality
3. Fastest response to inquiry, free sample evaluation
4. Good quality, good service, enjoy a high reputation in the industry
angle
Angle steel, commonly known as angle steel, is a long strip of steel with two sides at right angles to each other. Divided into
Isometric and unequal angles. According to the different needs of the structure, it can be made into various angles
Components can also be connected to each other. Widely used in various building structures and projects
Structures, such as beams, bridges, transmission towers, lifting and transporting machinery, ships, industrial furnaces,
Reaction tower, container frame, cable trench support, power pipeline, busbar support installation, warehouse shelf, etc.
Isometric
Dimensions (mm)
theoretical weight
(kg/m)
Dimensions (mm)
theoretical weight
(kg/m)
Dimensions (mm)
theoretical weight
(kg/m)
25x3
1.124
75x7
7.976
110x14
22.809
25x4
1.459
75x8
9.03
125x8
15.504
30x3
1.373
75x10
11.089
125x10
19.133
30x4
1.786
80x6
7.376
125x12
22.696
40x3
1.852
80x7
8.525
125x14
26.193
40x4
2.422
80x8
9.658
140x10
21.488
40x5
2.976
80x10
11.874
140x12
25.522
50x4
3.059
90x6
8.35
140x14
29.49
50x5
3.77
90x7
9.656
140x16
35.393
50x6
4.465
90x8
10.946
160x10
24.729
60x5
4.52
90x10
13.476
160x12
29.391
60x6
5.42
90x12
15.94
160x14
33.987
63x5
4.822
100x6
9.366
160x16
38.518
63x6
5.721
100x7
10.83
180x12
33.159
63x8
7.469
100x8
12.276
180x14
38.383
63x10
9.151
100x10
15.12
180x16
43.542
70x5
5.397
100x12
20.611
180x185
48.634
70x6
6.406
100x16
23.257
200x14
42.894
70x7
7.398
110x7
11.928
200x16
48.68
70x8
8.373
110x8
13.532
200x18
54.401
75x5
5.818
110x10
16.69
200x20
60.056
1. How can I get your quotation?You can leave us a message and we will promptly reply to each message. Or we can chat online through Trademanager. You can also find our contact information on the contact page.2. Can I get samples before order?Yes of course. We can produce according to your samples or technical drawings.3. What is your delivery time?Delivery time is usually around 1 month. If in stock, we can send out within 7 days.4. What is your payment terms?Our usual payment terms are 30% deposit and according to B/L. L/C is also acceptable.5. How can you guarantee that what I get is good?We are factory, 100% inspected before delivery, guaranteed quality.6. How do you make our business long-term and good relationship?We keep good quality and competitive price to ensure our customers benefit; we respect every customer as our friend, and we sincerely do business and make friends with them, no matter where they come from.
If you have any questions about us and our products, please feel free to leave us a message.
