Agfa 703 thermal CTP plate

  • $2.50 / >=2000 square meters
  • 2000 square meters
  • Hangzhou Sogo Graphics Ltd.
  • Zhejiang, China
  • Mr
PRODUCT DETAIL
place of origin; place of origin:Chinaapplication:commercial printing
brand:AgfaLabel:Huaguang
product name:Agfa Thermal CTP PlateMaterial:aluminum
Matrix:Electrochemical granulationport:any port in China
type:CTP platestyle:positive
0.30mm packing:50/boxShelf life:18 months
color:dark bluesafety lamp:yellow light
thickness:0.15-0.40mmuse:offset printing
size:custom sizemodel:703
Supply capacity:20000000 square meters / yearPackaging Details:0.30mm 50pcs/box
payment terms:L/C,D/A,D/P,T/T,Western Union,MoneyGramPackaging Preview:
detailed image
Product Description

Agfa 730 is a new thermal version independently developed by Agfa. Ltd. This high-quality thermal CTP plate is not only suitable for UV ink, but also for ordinary ink printing. The plate adopts high-quality aluminum double-coating formula; it has the characteristics of high sensitivity, good dot reproducibility, wide processing range and stable performance. It is compatible with all major platesetters and processors on the market.

Specification
plate type
Positive thermal plate
wavelength
830 nm
Sensitivity
120-140mJ/cm2
Resolution
1%~99%@200lpi
safety lamp
Unpack in sunlight or yellow light, and avoid strong light during plate making operations.
develop
It is recommended to use TPD-III developer (26±1°C, 25±5S)/TPD-80 developer (26±1°C, 25±5S), supplemented with the above developer.
run length
50,000 impressions, using UV ink; 300,000 impressions with ordinary ink;
storage

Plates should be stored in a dry and cool place. Shelf life is up to 12 months at temperatures between 15-27°C and RH 25-60%. They should also avoid places near water tanks, chemicals, or direct sunlight. The board should be used up as soon as possible after unpacking. If it needs to be stored for a short time, it should be placed in the original packaging and protected from light. Usually it can be placed for 8 hours under yellow light and 2 hours under white light or natural light.

Operation

Unpacking in daylight or yellow light, it is recommended that the plate making room avoid natural light. For manual or semi-automatic plate making equipment, when loading and unloading the plate, scratches should be avoided to avoid affecting the performance of the plate.
