Chico JY-100 semi-automatic double-head handbag gift box eyelet eyelet machine shoe eyelet eyelet machine
- $1350.00 / 1 - 4 sets
$1250.00 / >=5 sets - 1 set
- Hangzhou Qike Technology Co., Ltd.
- Zhejiang, China
- Ms Linda Lee
PRODUCT DETAIL
Packaging details: | wooden box | Cutting speed: | 195/minute |
brand: | Qike | Place of origin: | China |
Aperture: | 2.5mm-10mm | Electricity (kW): | 0.55kW |
payment terms: | L/C, D/A, D/A, wire transfer | weight: | 240 |
Core component warranty: | 1 year | port: | Shanghai/Ningbo |
weight: | 240kg | Core components: | engine |
usage: | boxes, shoes, paper | Name: | Eyelet primer |
strength: | 0.55kW | Dimensions (length*width*height): | 1000*620*1650mm |
Marketing type: | New products for 2022 | Showroom location: | not any |
Applicable industries: | Clothing Stores, Manufacturing Plants, Machinery Repair Shops, Food and Beverage Plants, Restaurants, Household, Retail, Print Shops, Construction Engineering, Energy and Mining, Food and Beverage Stores, Others, Advertising Agencies | Mechanical test report: | if |
Health status: | new | Voltage: | 380V/220V |
Supply capacity: | 200 sets per month | Video outbound inspection: | if |
speed: | 190 rpm | Hole spacing adjustment range: | 60-160mm, 120-220mm |
Voltage: | 220 volts | Warranty: | 1 year |
Product Description
Chico JY-100 semi-automatic double-head eyelet buttonhole machine handbag gift box shoe eyelet buttonhole machine
NailerThis machine is semi-automatic and can produce silk-marked paper-plastic bags with a thickness range of 0.1-0.5cm. Shoe leather. Widely used in handbags, carton ring production, archive bags, archive bag press rings, confidential files, ordinary file decoration, card binding, tag eyelets, anti-counterfeiting packaging bag sealing bags, clothing, hats, leather goods, leather products , leather products, leather products, leather products, leather products, Backete mattress air hole button production, etc.;
Name: JY-100 double-head eyelet machine Speed: 195/min Hole pitch adjustment range: Large pitch: 60-160mm Small pitch: 120-220mm Eye diameter: 2.5mm-10mm Electric power: 0.55kW Speed: 190rpm Dimensions: 1000 * 620*1650 Weight: 230kg
Machine features:1. The operation is simple, and the combination of perforation, buttonholes and hemming is formed at one time. The hole is automatically and continuously fed, and there will be noEyeletsPhenomenon. The structure is very reasonable. QEyeletsSmooth, no scratches on hanging objects. 2. It is especially suitable for punching corns on handbags. It is fast and can produce an average of 12,000 bags/day per machine. (otherEyeletsMachines cannot compare)
Size Information
Name | Double head corn eye machine |
Model | JY-100 |
speed | 195/minute |
Hole spacing adjustment range | Large distance: 60-160mm Small distance: 120-220mm |
Eye diameter | 2.5mm-10mm |
Voltage | 380V/220V |
weighing | 230kg |
