Cold Pad Batch Dyeing Machine CPB Textile Fabric Bleaching Machine

PRODUCT DETAIL
Port:ShangHai Seaport china;Warranty of core components:1 Year;
Machinery Test Report:Provided;Name:Cold Pad Batch Dyeing Machine;
Brand Name:RED FLAG;After Warranty Service:Video technical support,Online support,Spare parts,Field maintenance and repair service;
Video outgoing-inspection:Provided;Customized:Accept;
Function:Cooling Dyeing Process;Showroom Location:None;
Core Components:PLC,Engine,Bearing,Gearbox,Motor,Pressure vessel,Gear,Pump;Payment Terms:L/C,D/P,D/A,T/T,MoneyGram;
Control:PLC;Warranty:1 Year;
Applicable Industries:Manufacturing Plant,Other;Heating System:Steam;
Local Service Location:Egypt,Turkey,Viet Nam,Philippines,Indonesia,Pakistan,India,Mexico;After-sales Service Provided:Free spare parts,Field installation, commissioning and training,Field maintenance and repair service,Video technical support,Online support;
Speed:7-70M/min;Place of Origin:Jiangsu, China;
Operation:Auotmatic;Marketing Type:Hot Product 2019;

Product Description



Application: It is used for active agent cooling dyeing process, invariable tension, proportion supplying, center active batching and lifting to keep invariable gap according to fabric distance automaticlly.

Roller Width 1800-3200mm
Machine Speed Range 7-70M/Min
Drive Frenquency Conversion
Control Equipment PLC
Connection Value

17Kw

Supply Steam Pressure Min 0.2Mpa
Supply Compressed Air

Min 0.4Mpa

Supply Water Pressure Min 0.2Mpa
Overall Size(mm) 6550*4300*4500
