DC compressor frequency conversion controller 12v-24v refrigerator frequency conversion compressor driver board

PRODUCT DETAIL
type:refrigerator accessoriesOrigin:China
Supply capacity:10000 pieces per monthproject name:Refrigerator Inverter Compressor Driver Board Refrigerator Driver Board
payment terms:L/C, Western Union, T/T, MoneyGramstrength:120W
port:Ningbo, Shenzhen, Guangzhou, Qinzhougross weight:0.5 kg
Energy source:electricalPackage Size:15*9*5cm
application:Refrigerator, Freezer, Refrigerator, HouseholdWarranty:1 year
Compressor speed range:2000~3500 rpmHealth status:new
After-sales service provided:free spare partsmodel:ZY-CC100-DC12/24V-C
Voltage:DC9.6V~DC35Vmodel:ZY-CC100-DC12/24V-C
Packaging Details:Single package size: 15*9*5cm Single gross weight: 0.5kgs
Specification
● Suitable for DC compressor brushless motor with design voltage of DC40V. ● Suitable for QD25~QD35 DC compressor control with DC 12V or 24V power supply. ● Suitable for 30~150 liters DC refrigerators, solar DC refrigerators and freezers. ● All-aluminum shell design, easy installation, good heat dissipation. ● **Power limit ensures battery life and compressor reliability. ● Automatically identify and switch DC12V and DC24V power supply systems. ● Automatic variable boost (PAM) control to improve compressor efficiency. ● The temperature protection value of the controller is 85 degrees.
Product Description
model.
ZY-CC100DC12/24V-C
Voltage
DC9.6V~DC35V
Low voltage LV type DC8.5V)
strength
120W
Rotating speed
2000~3500 rpm
