Gravure printing machine 9 color cigarette case tipping paper printing machine

PRODUCT DETAIL
Supply capacity:4 sets per monthbrand:Yuncheng plate making
Marketing Type:Hot Products of 2022Voltage:380v
Printing material:BOPP.PET.PVC.PE.Aluminum foilColors and Pages:Polychromatic
type:Gravure printing machineUnwinding/rewinding diameter:600mm-800mm
Printing speed:200m/minAfter-sales service provided:On-site maintenance and repair services
Certification:CE ISO9001Applicable industries:Hotels, Building Materials Stores, Manufacturing Plants, Machinery Repair Shops, Food and Beverage Plants, Farms, Restaurants, Food Stores, Printing Shops, Energy and Mining, Food and Beverage Stores
Origin:Shanxi, ChinaCore components:PLC, engine, gearbox, motor, gear
usage:Paper Printers, Label Printers, Card Printersweight:35000 kg
Video shipment inspection:ifRegistration accuracy:0.1mm
Core component warranty:1 yearDimensions (L*W*H):15800*4400*3500mm
payment terms:L/C, D/P, D/P, T/TMechanical test report:if
Main selling points:easy to operateDrying method:oil heating
Automatic level:automaticWarranty:1 year
Printing color:1~12 colorsShowroom location:Egypt, Vietnam, Philippines, Indonesia, Pakistan, Russia, Thailand, Kenya, Bangladesh, Ukraine, Nigeria, Uzbekistan, Japan, Malaysia
Health status:newPrint width:800-1300mm
Product parameters
Film running direction from unwinding to winding
from left to right
printing color
8
maximum. Material width
1250mm
mechanical speed
200m/min (bore diameter ≥Φ175mm)
Unwinding diameter
Φ800mm
Rewinding diameter
Φ800mm
accuracy of registration
Horizontal ≤ ± 0.1mm (automatic) (constant speed) vertical ≤ ± 0.1mm (automatic) (constant speed)
Tension range
3~25kg
Tension accuracy
Rewinding and unwinding ±0.3kg
Traction ± 0.3kg
Core diameter
Φ76mm×Φ92mm
Rubber roller pressure
380 kg
Rubber roller hardness
(A) 70°~75°
cylinder diameter
Φ120mm~Φ300mm
cylinder length
1000-1350mm
Scraper reciprocating motion
±5mm
Air pressure
0.6Mpa≤P≤1.0Mpa
Maximum temperature of drying room
80°C
Hot air recovery rate
0~50%
Temperature control accuracy
±2℃
heating method
electricity or steam or gas
Maximum hot air velocity in drying chamber
25 m/s
Film length in drying chamber
Last color 1.6m 2m
printing material
PET: 12~60μm BOPP: 20~60μm

CPP: 20~60μmOPP: 20~60μm

Cellophane: 20~30μm
Main features of ELS machine
1. Independent disc-type rotary turret with double stations and wall panels
2. Two unwinding shafts adopt independent active unwinding mode
3.Automatic paper pick-up alarm, new paper rotation, pre-drive speed synchronized with machine speed.
4.Synchronous belt makes transfer more convenient and less noise
5.Double cylinder consists of steel and rubber rollers
6.The scraper assembly adopts pneumatic control and can be adjusted in three directions through the handle
7.Remote Service
8.Separate Drive Motor Inverter
9.Each unit is equipped with an independent drying system
10.Touch HMI
11.Energy saving and environmental protection
detailed drawing
Gravure printing machine structure:
- Unwinding device
- Feed section
- print section
- dry part
- cooling section
- Discharge part
- Rewinding device
