HG8245H EPON/XPON ONU 4LAN+2POTS+2.4G WiFi 5db hg8245h5 OEM customized LOGO GPON ONT bridging and routing fiber optic equipment F460 F660
- $4.00 /piece
- 1 piece
- Ecom-Tech Co., Ltd.
- Guangdong, China
- Mr shadow Chen
PRODUCT DETAIL
Interface Protocol: | 4GE, STM-1, STM-4, STM-16 | Supply capacity: | 3000 pieces per week |
Function: | Fiber optic signal transmission/Modem | model: | HG8245H |
Origin: | Guangdong, China | brand: | Processing |
color: | white | type: | FTTx solution, FTTH |
use: | FTTH | payment terms: | L/C, Western Union, T/T, VISA, Pay Later, Alipay |
Certificate: | CE ROHS FCC | firmware: | English |
shell material: | plastic | application: | FTTH/FTTB/FTTN |
Packaging Details: | Sales quantity: 1 piece/box Single package size: 280mm*197mm*90mm Single package weight: 827g Carton packaging: 20 boxes/carton | port: | Shenzhen Guangzhou Hong Kong |
Warranty: | 1 year |
4LAN+2POTS+2.4G WiFi 5dbi Antenna Network Unit Fiber Optic Modem Equipment EPON/GPON/XPON Terminal
Product Description
Product Description | ||
technical project | illustrate | |
Model | HG8245H | |
The output port contains | 4FE+2TEL+1USB+2.4G WiFi | |
WIFI signal |
|
|
wireless gain | 5 decibels | |
USB | USB2.0 | |
local area network | 1*10/100Mbps adaptive Ethernet port, full/half duplex, RJ45 interface | |
Telephone | H248/SIP voice protocol | |
PPPOE | support | |
firmware | English | |
size and weight | 266mm*178mm*80mm/445g | |
Fiber port | 1 GPON/EPON/XPON interface, single fiber, downlink rate 2.5Gbps, uplink rate 1.25Gbps | |
wavelength | Transmit 1310nm, receive 1490nm | |
fiber optic interface | SC/FC-UPC/APC Dual Mode/Single Mode | |
Receiver sensitivity | >-28dBm (1490nm) | |
DC power supply | 12V 1.5A, external AC-DC power adapter | |
button | Reset, Power, WPS, Wireless | |
Operation | Working temperature: -5-+55℃ Working humidity: 10-90% (no condensation) | |
storage | Storage temperature: -30°C- +60°C Storage humidity: 10-90% (no condensation) |
feature | |
1. Plug and play: One-click service deployment on the network management system without on-site configuration. | |
2. Remote diagnosis: realize remote fault location through POTS port loop test, call emulation, PPPoE dial emulation, etc. | |
3. Link monitoring: use 802.1ag Ethernet OAM to realize end-to-end link detection. | |
4. High-speed forwarding: 900Mbit/s forwarding in NAT scenarios. | |
5. IPv6 capability: support IPv6/IPv4 dual stack and DS-Lite. |
