Rexroth linear guide slider R162341220 R162342320 R162342220
- $20.00 /piece
- 1 piece
- Shandong XRT Bearing Co., Ltd.
- Shandong, China
- Ms Amy Zhang
| payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram, PayPal | size: | 45mm |
| Core components: | Linear guide block | Rated static load: | 128500N |
| Marketing type: | normal product | Applicable industries: | Manufacturing plants, machine repair shops, household, retail, energy and mining, other |
| brand: | Rexroth | port: | Qingdao, Guangzhou, Shanghai |
| Mechanical test report: | not available | Warranty: | 1.5 years |
| Ball chain: | Without ball and chain | Health status: | new |
| Preload level: | C2 | feature: | High rigidity; |
| Block type: | block | Core component warranty: | 1 year |
| Showroom location: | not any | weight: | 3.2kg |
| Video outbound inspection: | not available | Packaging details: | original package |
| Supply capacity: | 500,000 pieces per month | Rated dynamic load: | 90400N |
| Material: | Carbon steel | level of accuracy: | phosphorus |
Rexroth linear guide slider R162341220 R162342320 R162342220
| product name | Rexroth linear guide slider R162341220 R162342320 R162342220 |
| brand | Rexroth |
| Material | Carbon steel |
| size | 45mm |
| Preload level | C2 |
| level of accuracy | phosphorus |
| high | 50.3 mm |
| width | 86 mm |
| length | 174.1mm |
| Block weight | 3.2kg |
| Rated dynamic load | 90400N |
| Rated static load | 128500N |
| application | CNC machine tools |
feature
Size 45
Format SNH: width = slender, length = normal, height = tall
Slider body made of non-alloy steel CS
Preload level C2: medium preload
Accuracy level P: precision level
Without ball and chain
Has initial lubrication and anti-corrosion effects
Roller bearing grease Dynalub 510
Without connecting elements, left (front reference edge)
Without connecting elements, right side (front reference edge)
Straight lube connection is loose.
Standard slider body
Total slide length = 137.6 mm
Interchangeability: Slides and guide rails can be combined with each other with various accuracies.
- Application areas: occasions with limited lateral space and high rigidity requirements
- Higher rigidity than SNS
- Significant reduction in frictional vibrations and low friction levels, especially under external loads
- Maximum accuracy
- Patented entry zone increases stroke accuracy six times
- High stiffness in all load directions – allows applications using only one slide per rail
- High torque load capacity
- Unlimited interchangeability, since all ball guide rail systems can be freely combined with all ball runner block versions within every accuracy class.
- Long-term lubrication can be achieved for several years
- End-face fastening thread for all accessories
- Smooth and quiet operation thanks to optimized design of ball return and guide rails
- Different preload levels
- Excellent dynamic characteristics
- Can be used on all SNS/SNO ball guides
- Ball runner blocks are pre-lubricated at the factory
- Significant reduction in frictional vibrations and low friction levels, especially under external loads
- Higher rigidity than SNS
- Maximum accuracy
- Application areas: occasions with limited lateral space and high rigidity requirements
- Patented entry zone increases stroke accuracy sixfold
