Steel Bar Cutter
- $27.49 /piece
- 1 piece
- Jiaxing Pink Electronic Technology Co., Ltd.
- Zhejiang, China
- Mr Jack Zhang
| Showroom Location: | None; | Applicable Industries: | Machinery Repair Shops,Manufacturing Plant,Farms,Home Use,Retail; |
| Marketing Type: | Hot Product 2019; | Year: | 2019; |
| Material: | Steel; | Port: | Shainghai; |
| Weight (KG): | 10; | Condition: | New; |
| Place of Origin: | Zhejiang, China; | Video outgoing-inspection: | Provided; |
| Brand Name: | PINK; | After-sales Service Provided: | Free spare parts,Online support,Video technical support; |
| Type: | Shearing Machines; | Blade Length: | 5",6",8",10",12"; |
| Application: | Industrial Metal Cutting; | Rated Power: | Manual; |
| Dimension(L*W*H): | 33*16*13,50*16*45,74*15*44cm; | Warranty: | 1 Year; |
| Machinery Test Report: | Provided; | Payment Terms: | L/C,D/P,T/T,Western Union; |
| Voltage: | Manual; | Capacity: Flat Steel: | 70*6mm; |
| Local Service Location: | None; | Key Selling Points: | Multifunctional; |
| N.W: | 9,11,17,21,26,42kg; | Name: | Metal Hand Shear; |
| After Warranty Service: | Video technical support,Online support,Spare parts; | Certification: | CE GS; |
| Warranty of core components: | 1 Year; | Supply Ability: | 15000 Pieces per Month; |
| Power (kW): | 0; | Packaging Detail: | Carton Box packing; |
| Capacity: Sheet Steel: | 6.0mm; | Capacity: Round Steel: | 11,13mm; |
| Core Components: | Machine; |
1.Blade Length:5",6",8",10",12"
2.Capacity: Sheet Steel:6.0mm
Flat Steel:70*6mm
Round Steel:11,13mm
3.N.W:9,11,17,21,26,42kg
4.Material:Steel
5.Certificate:GS,CE
Metal Hand Shear Details & Function:
1. The structure of the shear trigger mainly includes: transmission system, slider (tool holder), bed (rack), pressing mechanism, material blocking mechanism, balancer, electrical control system and other auxiliary devices.
2. The workbench is generally cast iron, bolted to the front of the bed. In order to reduce the friction of the sheared sheet on the workbench, the shearing machine's workbench is equipped with a supporting steel ball. The lower end of the steel ball is provided with a spring.
3. The body of the manual shearing machine is welded by steel plate. The cutting range: various metal sheets, various steel mesh, various wire, wire and so on.
4. Features: Cutting range 0.2mm-2.5mm various metal sheets, various steel mesh, various wire, wire and so on. The processing edge material is 65 manganese and has a hardness of 55 degrees. The punching force is large, the knife is synchronized, the force is even, the force is easy, and the two can be cut horizontally.
5. It can be installed by the manual shearing machine. The high-quality low-carbon steel is selected from the frame of the manual shearing machine. The tool part is made of high-quality tool steel and is manufactured by advanced technology. Its structure is simple and beautiful, easy to use, multi-purpose, and can cut steel plate. It can also cut steel bars and is widely used in sheet metal, construction, hardware, maintenance and other industries. It is an ideal manual cutting tool.
Manual shearing machine features
1. The punching force is large, the knife is synchronized, the force is even, the force is easy, and the two can be cut horizontally.
2. It can be installed with the positioning plate to make the accuracy more accurate, less deformation, low loss and high efficiency.
3. It is the most ideal cutting tool for steel mesh suppliers and enterprises in various factories for forming and trimming.
Clipping machine advantages
1. Work safety, can prevent equipment failure caused by overload.
2. Simple structure, easy to manufacture, short production cycle and low cost.
3. It is easy to operate, and can realize single stroke, continuous stroke, jog stroke, stop midway stop and return stroke.
4. Small vibration, stable operation, low noise and long tool life.
| Model | Product Name | Specification | Packing Size(cm) | G.W/N.W (kg) |
Loading 20GP(pcs) |
| NEHDS-01 | Hand Shear | Blade Length:5" Capacity: Sheet Steel:6.0mm Flat Steel:70*6mm Round Steel:11mm |
33*16*13 | 10/9 | 3787 |
| NEHDS-02 | Hand Shear | Blade Length:6" Capacity: Sheet Steel:6.0mm Flat Steel:70*6mm Round Steel:11mm |
33*16*13 | 13/11 | 3787 |
| NEHDS-03 | Hand Shear | Blade Length:8" Capacity: Sheet Steel:6.0mm Flat Steel:70*6mm Round Steel:13mm |
50*16*45 | 19/17 | 722 |
| NEHDS-04 | Hand Shear | Blade Length:10" Capacity: Sheet Steel:6.0mm Flat Steel:70*6mm Round Steel:13mm |
74*15*44 | 23/21 | 532 |
| NEHDS-05 | Hand Shear | Blade Length:12" Capacity: Sheet Steel:6.0mm Flat Steel:70*6mm Round Steel:13mm |
74*15*44 | 28/26 | 532 |
Jiaxing Pink Electronic Technology CO., LTD. is an enterprise that specializes in electric tool, we export during the past 10 years.
We emphasize and concentrates on professional services to our clients. We believe that excellent quality of products, timely delivery of goods, and competitive prices are the keys to establish and maintain the long term business relationships with our customers in a mutual beneficial way.
Our company is about 120km far from Shanghai in the east and 90km far from Hangzhou in the west, it enjoys very convenient transportation. Sincerely welcome every customer to visit our factory.
If you are interested in our Metal Hand Shear, please don't hesitate to contact us.
