The newly designed high quality waterproof IP66 12W LED outdoor linear building lamp is suitable for bridge contour lighting

PRODUCT DETAIL
Led type:5050;Port:Shenzhen;
Brand Name:LNJAMI;CRI (Ra>):80;
Beam angle:110 Degree;Lighting solutions service:Lighting and circuitry design,DIALux evo layout,auto CAD layout;
Power Range:12W 15W or custom;Application:Building facade/landscape;
Control mode:DMX512/ Customized (0-10V/ Triac/ Dali);Size:L1000*W21*H63mm;
Payment Terms:L/C,Western Union,D/P,D/A,T/T,MoneyGram;Light Source:LED;
Color Temperature(CCT):2700K-6000K;Warranty(Year):3-Year;
Model Number:XT21MW48D2;Name:12W LED Outdoor Linear Architecture Light;
Cover:Milky white PC;Lamp Body Material:Aluminum Alloy;
Working Lifetime(Hour):50000;Item Type:RGB Tubes;
Lamp Luminous Efficiency(lm/w):80;Working Temperature(℃):-20 - 50;
Input Voltage(V):DC24V;Supply Ability:30000 Pieces per Month;
IP Rating:IP66;Housing Color:Silver/Custom;
Place of Origin:Guangdong, China;Packaging Detail:1pc/box, 20boxes/carton;
Color of light:R/Y/B/G/WW/CW/RGB/RGBW;

Waterproof IP66 12W LED Outdoor Linear Architecture Light for Building Bridge Square Outline Lighting



Model No. Length(mm) Input voltage Rated  power LED's Color of light Beam angle IP Grade
XT21MW48D2 1000/500/300   DC24V 12W 48*0.2W

2700K/3000K

/4000K/6000K

130°

IP66
XT21MW48D2A 1000/500/300  DC24V   12W 48*0.2W RGB DMX512     8 Pixels   130°  IP66
XT21MW48D2B  1000/500/300
DC24V 15W 48*0.3W

 RGBW DMX512     8 Pixels

130°

IP66



Product Description





Application



Company Information

Certifications

Exhibition



FAQ

Q1. Why Choose Us?

  • Products focus on LED wall washer light, LED linear light, LED flood light, LED outdoor panel light

    and LED underground light with more than 12-year experience.

  • Most of our products have CCC, CE, ROHS certificates, design patents and ISO9001: 2015.



 Q2. What is the warranty and how to deal with the faulty?

  • Firstly, 3-5 years warranty. Products are produced in strict quality control system, the defective rate less than 0.1%.

  • Secondly, during the guarantee period, we will send replacements with new order for small quantity.

    For mass defective products we will repair them and resend them to you, or we can discuss the new solution.



Q3. I don't know which product is suitable for our project, can you make suggestions?

  • Yes, firstly, we can offer our professional solution including effect picture design (static, dynamic),

     product selection table, lighting control system diagram, installation serial port diagram and so on.

  • Secondly, we can offer complete after-sales service including installation guidance and commissioning.



Q4. What about the lead time? and can I have a sample order?

  • 3-5 working days for samples and 10-15 working days for mass production. Welcome sample order to check quality.



 Q5. Do you provide OEM and ODM services?

  • Yes, OEM and ODM are welcome. We can offer product and package customization from design to production.
