Tungsten wire 5.8mg tungsten rod for halogen filament

PRODUCT DETAIL
payment terms:L/C, T/TPackaging Details:According to customer requirements (carton packing/vacuum packing)
Wire Gauge:According to customer requirementsPackage preview:
Supply capacity:15000 km per monthport:Ganzhou, China
brand:Ganzhou Hongfeimodel:W31;WB61;WB91
place of origin; place of origin:Jiangxi, China





Tungsten wire 5.8mg tungsten rod for halogen filament



This tungsten wire is used in the manufacture of halogen filaments, shock-resistant filaments, and other high-temperature-resistant devices.



1) Type and application



Types of

application

WB91

Used in the manufacture of high temperature resistant devices such as halogen filaments and shock-resistant filaments

WB61

Suitable for manufacturing helical coil or triple CFL filaments.

WB31

Used in the manufacture of incandescent lamps and supporting wires, etc.



2) Diameter tolerance



diameter (um)

Weight (mg/200mm)

200mm weight tolerance





0

I

two

10

0.30-0.98

----

±3.0

±4.0

18

0.98-4.85

±2.0

±2.5

±3.0

40

4.85-19.39

±1.5

±2.0

±2.5

80

19.39-272.71

±1.0

±1.5

±2.0

300

272.71-371.19

----

±1.0

±1.5



notes:



The diameter range can be customized according to customer requirements.



The product complies with the technical standard of HFQI-26.



The diameter range can be customized according to customer requirements.
