VRF system R410A DC central air conditioner

Price:$139.00 /set
Min. Order:1 set
Supplier:Shandong Rivast Air Conditioning Co., Ltd.
Region:Shandong, China
Contact:Ms Yolanda Wang

PRODUCT DETAIL

Marketing Type:	New Products 2020	Warranty:	1 year
Core components:	motor	product name:	Cassette fan coil unit
Types of:	Fan coil	Applicable industries:	Hotels, clothing stores, building supplies stores, machinery repair shops, manufacturing plants, food and beverage factories, farms, restaurants, home use, retail, food stores, printing shops, construction, energy and mining, food and beverage stores, advertising agencies
State of health:	new	port:	Tianjin port or Qingdao port
Install:	ceiling mount	brand:	Xinjiang Han
Video shipment inspection:	if	Mechanical test report:	if
Local service location:	not any	Operating Voltage:	220V
application:	restaurant hospital hotel etc.	Certification:	CE certification
payment terms:	L/C, T/T, Alibaba Trade Assurance	Heating capacity:	2700~18900W
Material:	Galvanized steel	Showroom location:	not any
Package preview:		manufacturer:	China
brand:	Xinjiang Han	After-sales service provided:	online support
air flow:	2380	After warranty service:	Video technical support, online support
Cooling capacity:	1800~12600W	color:	white
Core component warranty:	1 year	place of origin; place of origin:	Shandong China
Packaging Details:	VRF system R410A DC central air conditioner	Fan type:	ceiling box
Main selling points:	easy to operate	Supply capacity:	30 sets per day

Product Description

What are VRFs?

Compared to other HVAC systems available, VRF systems are among the most advanced and energy efficient air conditioning systems available. A VRF system has four defining characteristics.

1. First, these systems use refrigerant only to generate cool air. Compare this to a traditional HVAC system that uses water to cool the air. In traditional systems, the refrigerant is only used to cool the water, which is then circulated through the system.

2. Second, the VRF system uses an inverter compressor. These low-energy compressors draw very limited power and only allow the unit to extract enough energy to partially cool the system.

3. Next, VRF systems have multiple air handlers that can be connected together in the same refrigerant circuit.

4. Finally, this defined function enables the VRF system to be modularly scalable for growing projects.

The fan coil unit is mainly composed of a centrifugal fan and a coil heat exchanger. It is the terminal equipment of the central air conditioning system. The fan sends indoor air or outdoor mixed air into the air cooler for cooling or heating and then sends it into the room to reduce or increase the indoor temperature to meet people's comfort requirements.

Model and performance			FP-34	FP-51	FP-68	FP-85	FP-102	FP-136	FP-170	FP-204	FP-238
Rated air volume m3/h		High	340	510	680	850	1020	1360	1700	2040	2380
		Moderate	260	390	510	640	770	1020	1280	1530	1790
		low	170	260	340	430	510	680	850	1020	1190
Rated cooling capacity KW		h	1.98	2.8	3.87	4.58	5.42	7.38	9.08	11.1	12.9
Rated cooling capacity KW		h	1702	2408	3328	3938	4661	6346	7808	9546	11094
Rated heating capacity KW		h	3.39	4.5	6.35	7.45	9.22	12.4	16.3	19.5	20.2
Rated heating capacity KW		h	2915	3870	5460	6407	7930	10665	14020	16770	17370
Input power W	12Pa	h	37	52	62	76	96	134	152	189	228
	30Pa	h	44	59	72	87	108	156	174	212	253
	50Pa	h	49	66	84	100	118	174	210	250	300
Noise decibel(A)	12Pa	h	37	39	41	43	45	46	48 years old	50	52
	30Pa	h	40	42	44	46	47	48 years old	50	52	54
	50Pa	h	42	44	46	47	49	50	52	54	56
Water flow Kg/h			350	510	660	800	980	1280	1600	1920	2230
Water resistance Kpa			30	30	30	30	40	40	40	40	50
power supply			220V/50Hz
