White Calculator 4 Raised and Submerged Position Dip Switch Smd

Price:$0.10 / >=1000 pieces
Min. Order:1000 pieces
Supplier:Switech Electronics Co., Ltd.
Region:Jiangsu, China
Contact:Mr John Lee

PRODUCT DETAIL

payment terms:	L/C, Western Union, T/T, Paypal	Electrical life:	1000 operating cycles per switch 24VDC, 24mA
Packaging Details:	125 pieces per box, 5 boxes per inner box, 4 inner boxes per box, 2500 pieces per box.	Supply capacity:	5,000,000 pieces per month
Dielectric strength:	300VAC	Insulation resistance:	Minimum 100MΩ
Operating temperature:	-40℃~+85℃	maximum. current:	100mA
Certification:	ce	Non-Switching Ratings:	100mAA DIP switch
maximum. Voltage:	250V	port:	Shanghai
model:	SW-DR	Origin:	Taiwan, China
Operating force:	Maximum 500gf	brand:	Svitek
Mechanical life:	1000 operating cycles per switch	capacitance:	5pf max

Product Description

switch function	spst, 1 to 12 positions
contact rating	Switching: 25mA @24 VDC Carrying: 100mA @50 VDC
Insulation resistance	100 Ω min @500VDC
Contact resistance	Initial value: 50mΩ@24VDC @100mA After service life: 100mΩ@24VDC @100mA
service life	2000 male on-off cycles per circuit
operating force	Maximum 1000gf
Dielectric strength	500V RMS min@sea level between adjacent terminals
capacitance	Maximum 5pf between adjacent terminals
temperature range	Working/Storage: -40°C to 85°C
vibration	Conforms to mil-STD-202F. Method 213B, Condition A
Shock	Conforms to mil-STD-202
Welding recommendation	wave :260 ℃ for 5 sec max. Hand: 30w soldering iron 320 ℃ 2s typical value. Keep all switches in the "OFF" position while welding and cleaning process.
