Best Selling DM40 Variable Speed ​​Bench Drilling Machine

  • $199.00 /piece
  • 1 piece
  • Sjr Machinery Co., Ltd.
  • Jiangsu, China
  • Mr Jerry Lu
PRODUCT DETAIL
Spindle speed range (rpm):75 - 1600 rpmAfter warranty service:Video technical support, online support, spare parts, on-site maintenance and repair services
Applicable industries:Building material stores, manufacturing plants, machinery repair shops, construction projectsport:FOB Shanghai
Origin:Jiangsu, ChinaCore component warranty:1 year
Supply capacity:20 pieces per monthCertification:different
usage:GeneralPower (kW):1.1
Processing:vertical milling machineDimensions (L*W*H):820x760x1150mm
Function:metal millingpayment terms:L/C, Western Union, D/P, D/A, T/T, MoneyGram
model:DM40Local service location:Egypt, Canada, Algeria
color:custom madeShowroom location:Egypt, Canada, Algeria
type:Drilling and Milling MachineKey words:Milling Machine Manual
maximum. Drilling diameter (mm):40Marketing Type:New Products 2020
Main selling points:competitive priceWeight (kg):300 kg
CNC or not:CNCHealth status:new
accurate:high precisionWarranty:1 year
Voltage:380vType of machine:vertical
use:hobbiesapplication:metalworking milling machine
Packaging Details:Wooden box, iron or wooden pallet with waterproof membraneproduct name:metal milling machine
Video shipment inspection:ifCore components:Motor, gearbox, PLC
brand:FalcoAfter-sales service provided:Online support, video technical support, free spare parts, on-site installation and commissioning training, on-site maintenance and repair services
Mechanical test report:if
Recommended Products
Product Description
This machine is mainly suitable for turning pipe ends, tapered pipe threads, pipe collars, pipe sleeves, drill pipes, etc. It has the characteristics of high power, good rigidity, high precision, and good retention performance. It adopts FANUC or SIEMENS numerical control system, which guarantees safety and reliability. For the reliability of the machine, the pulse encoder is used as the measuring element, and the longitudinal and lateral feeds form a semi-closed-loop control.





Drilling and milling machine is a small and medium-sized general-purpose metal cutting machine tool, which can mill horizontally or vertically. Suitable for drilling, reaming, reaming, boring and hole processing; For example, with disc milling cutters, angle milling cutters, form milling cutters, and end mills, planes, inclined surfaces, elevations, grooves, etc. can be milled out. After installing the accessory end mill head, it can be used as a multi-purpose directional milling job.




The bed is installed on the base, and the main motor is installed on the lower abdomen of the bed. It is transmitted to the I-shaft through a pair of V-belt pulleys and enters the gearbox of the bed, and then transmitted to the main shaft through six pairs of gears. The front end of the spindle is a Morse No. 4 taper hole. The other end of the long knife bar is supported in the bearing hole of the hanger, and the knife bar support is installed on the dovetail guide rail of the sliding arm.
Product parameters
thing
scope
maximum. Drilling diameter (steel/iron)
31.5/40mm
Maximum mill capacity (end face/end face)
80/32mm
Spindle taper
MT3/MT4/R8/ISO30
working desk size
730×210mm
Table travel X/Y
500/230mm
head tilted left and right
90°
Spindle box rotation
360°
Spindle travel
130mm
Spindle nose to table
470mm
Spindle speed (option)
6 gears: 60Hz 90~1970rmp 50Hz 75~1600rmp
engine
1.1 kW
Net weight/Gross weight
270/300KG
Packing size (length x width x height, including feet)
820×760×1150mm
20' container
30 sets
