Gilbarco Fuel Dispenser Filters, High Quality at Great Prices
- $5.00 / 100 - 299 sets
$4.50 / 300 - 999 sets
$4.30 / >=1000 sets - 100 sets
- Qingdao Alptec Safety Equipment Co., Ltd.
- Shandong, China
- Ms Catherine Zhang
| Single package size: | 40X40X40 cm | application: | for service station distributor |
| Marketing Type: | New Products 2020 | Function: | Removes rust, dust and induced water |
| After Warranty Service: | Video technical support, online support, spare parts | Sales unit: | single product |
| Health status: | new | Core components: | Pump |
| Local service location: | South Africa | After-sales service provided: | Engineers can repair machinery overseas, video technical support |
| Filter Type: | Spin-on filter | Applicable industries: | Gas station |
| place of origin; place of origin: | Shandong China | Packaging Details: | Plastic and carton |
| Video external inspection: | if | Warranty: | 2 years |
| Core Components Warranty: | 2 years | product name: | Water Detection and Particulate Removal Filters |
| Showroom location: | South Africa | Certificate: | ISO9001 |
| Gross weight per piece: | 2.000 kg | Mechanical test report: | Not available |
| brand: | Ober |
Size Information | ||
media type | super absorbent medium | |
diameter | 3.68'' | |
high | 5.43'' | |
Wire | 1'' – 12 UNF or 1 1/2''-16 UNF | |
flow | 25 gpm (94.6 l/min) | |
operation (max) | 50 psid (3.4 bar) | |
maximum operating temperature | 250°F (139°C) | |
minute. Operating temperature | -22°F (-30°C) | |
AB-P series
1. AB25-P and AB38-P types are particulate matter
Removal and Water Detection Spin-on filters are designed to remove particulates and detect free and emulsified water in pure gasoline with slow flow as an indicator of the presence of water in pure gasoline.
2. The filter will not sense water in ethanol mixed gasoline, nor will it react. (The reaction is called phase separation).
3. AB25-P type adopts standard 1"-12 UNF mounting thread
4. AB38-P type adopts standard 1 1/2"-12 UNF mounting thread
5. AB25-P and AB38-P filters can effectively remove 10 microns or 20 microns or 30 microns of particulate matter, and detect free water and emulsified water in pure gasoline.
AB-D series
1. Models AB25-D and AB38-Dare Particle Removal and Water Sensing Spin-On Filters are designed to remove particles and detect free and emulsified water in pure gasoline with slow flow as an indicator of the presence of water in diesel.
2. The filter will not sense water in ethanol mixed gasoline, nor will it react. (The reaction is called phase separation).
3. AB25-D type adopts standard 1"-12 UNF mounting thread
4. AB38-D type adopts standard 1 1/2"-12 UNF mounting thread
5. AB25-D and AB38-D filters can effectively remove 10 microns or 20 microns or 30 microns of particulate matter, and detect free water and emulsified water in diesel fuel
AB-E series
1. Models AB25-E and AB38-E are spin-on filters designed to remove particulates, detect and slow the flow of phase separation (ethanol to water) in ethanol blended fuels.
2. It will not induce or react to water in non-alcoholic mixed gasoline (pure gasoline).
3. Both AB25-E and AB38-E filters provide efficient 10-micron or 30-micron particle removal and phase separation detection.
