Gilbarco Fuel Dispenser Filters, High Quality at Great Prices

PRODUCT DETAIL
Single package size:40X40X40 cmapplication:for service station distributor
Marketing Type:New Products 2020Function:Removes rust, dust and induced water
After Warranty Service:Video technical support, online support, spare partsSales unit:single product
Health status:newCore components:Pump
Local service location:South AfricaAfter-sales service provided:Engineers can repair machinery overseas, video technical support
Filter Type:Spin-on filterApplicable industries:Gas station
place of origin; place of origin:Shandong ChinaPackaging Details:Plastic and carton
Video external inspection:ifWarranty:2 years
Core Components Warranty:2 yearsproduct name:Water Detection and Particulate Removal Filters
Showroom location:South AfricaCertificate:ISO9001
Gross weight per piece:2.000 kgMechanical test report:Not available
brand:Ober
Specification
Size Information
media type
super absorbent medium
diameter
3.68''
high
5.43''
Wire
1'' – 12 UNF or 1 1/2''-16 UNF
flow
25 gpm (94.6 l/min)
operation (max)
50 psid (3.4 bar)
maximum operating temperature
250°F (139°C)
minute. Operating temperature
-22°F (-30°C)
Product Description

AB-P series

1. AB25-P and AB38-P types are particulate matter

Removal and Water Detection Spin-on filters are designed to remove particulates and detect free and emulsified water in pure gasoline with slow flow as an indicator of the presence of water in pure gasoline.
2. The filter will not sense water in ethanol mixed gasoline, nor will it react. (The reaction is called phase separation).
3. AB25-P type adopts standard 1"-12 UNF mounting thread
4. AB38-P type adopts standard 1 1/2"-12 UNF mounting thread
5. AB25-P and AB38-P filters can effectively remove 10 microns or 20 microns or 30 microns of particulate matter, and detect free water and emulsified water in pure gasoline.

AB-D series

1. Models AB25-D and AB38-Dare Particle Removal and Water Sensing Spin-On Filters are designed to remove particles and detect free and emulsified water in pure gasoline with slow flow as an indicator of the presence of water in diesel.
2. The filter will not sense water in ethanol mixed gasoline, nor will it react. (The reaction is called phase separation).
3. AB25-D type adopts standard 1"-12 UNF mounting thread
4. AB38-D type adopts standard 1 1/2"-12 UNF mounting thread
5. AB25-D and AB38-D filters can effectively remove 10 microns or 20 microns or 30 microns of particulate matter, and detect free water and emulsified water in diesel fuel

AB-E series

1. Models AB25-E and AB38-E are spin-on filters designed to remove particulates, detect and slow the flow of phase separation (ethanol to water) in ethanol blended fuels.

2. It will not induce or react to water in non-alcoholic mixed gasoline (pure gasoline).

3. Both AB25-E and AB38-E filters provide efficient 10-micron or 30-micron particle removal and phase separation detection.
