High-efficiency smokeless carbonization furnace is suitable for carbonizing various wood stoves

PRODUCT DETAIL
Supply capacity:100 acres per dayMain selling points:Easy to operate
port:Qingdaobrand:Runxiang
payment terms:L/C, Western Union, D/P, D/A, T/T, MoneyGramEffective volume:8 parties
Health status:newApplicable industries:Manufacturing plants, energy and mining, other
Mechanical test report:ifCore component warranty:2 years
Dimensions (length*width*height):4.7m*1.8m*2.2mMarketing type:2020 new products
Package preview:Core components:PLC, engine
Video outbound inspection:ifShowroom location:Kenya
Warranty:1 yearWeight (kg):45000
Packaging details:woodenPlace of origin:Henan, China
Product Description

New energy-saving carbonization furnace

The new energy-saving carbonization furnace adds a flue gas recovery device based on the original old-fashioned carbonization furnace. After the flue gas is recovered, it can be dust-free and smoke-free (smoke-free note: the equipment is designed to reduce flue gas. The so-called smoke-free means less smoke. The smoke is light. The reason for the smoke generated during the combustion process is oxygen. Insufficient, insufficient combustion.) The recovered smoke can be ignited like liquefied gas and can provide an ignition source for the dryer.
Wood carbonization equipment (used for carbonization machine rods, logs, branches, wood blocks, coconut shells, scraps from wood processing plants, etc. This equipment can be equipped with a purification device to recover gas and turn it into a gas carbonization furnace or other); new type The energy-saving carbonization furnace has dual-purpose functions. The material can also be directly carbonized, or first made into rods and then carbonized.
Work principles

Send the raw materials into the carbonization furnace and lock the furnace door, and finally seal the furnace. Use wood or other fuel to heat the raw materials in the furnace, and discharge the moisture in the raw materials and the air in the inner tank. When the temperature in the carbonization furnace rises to the point where a small amount of yellow smoke (hydrogen, oxygen and other volatile substances) is emitted from the smoke pipe. That is, the carbonization process starts, and then the combustible flue gas is recovered and ignited into the furnace to adjust the air intake. When the combustion in the furnace stops naturally, the carbonization is completed. When the carbonization is completed, the cooling water valve needs to be opened to cool the inner tank. When the temperature of the inner tank drops below 50°C, the furnace door can be opened to discharge the carbon..
Features

1. The reason why it is called an energy-saving carbonization furnace is because the wood sticks will produce a large amount of light yellow combustible gas during the carbonization process. These gases can be directed through the pipes of the carbonization furnace itself to the combustion zone at the bottom of the carbonization furnace for secondary fire heating. Environmentally friendly and fuel efficient.

2. This carbonization furnace adopts horizontal manufacturing process. The structure of the carbonization furnace is three layers, with lightweight insulation materials in the middle to keep the temperature in the furnace from losing. The furnace door is sealed with boiler packing to prevent air from entering, and the char formation rate is much higher than that of conventional carbonization furnaces.



3. The excess gas discharged from the carbonization furnace can be used in the dryer or to provide a heat source. The cooling time after combustion in the carbonization furnace is shorter. Utilize the gap between the interlayers to use water to cool the carbonization furnace for natural cooling, which is faster and more convenient.
Specification
Model
RXTH-04
RXTH-08
RXTH-14
weight
2.5 tons
4.5 tons
6 tons
size
3*1.7*2.1m
4.5*1.9*2.3m
5*2.1*2.5m
Carbonization time
12 hours
12 hours
12 hours
capacity
800-1000kg
1800-2000kg
2800-3000kg
volume
4 parties
8 parties
14 square
