Low temperature resistant fluorine rubber FKM FPM GFLT 600S rubber compound
- $250.00 / >=25 kilograms
- 25 kilograms
- Chengdu Eson New Material Co., Ltd.
- Sichuan, China
- Ms Lily Luo
| payment terms: | wire transfer | Material: | Fluorocarbon Rubber |
| Supply capacity: | 1000 tons per year | Package preview: | |
| Origin: | China | color: | Black, brown, gray, red, etc. |
| model: | GFLT 600S | port: | Shanghai Port |
| hardness: | 60-90 Shore A | feature: | Low temperature resistance |
| brand: | love life | Packaging Details: | 25kg/bag, 1000kg/pallet |
| Processing: | Compression molding, extrusion, injection and calendering | Curing system: | peroxide |
Low TemperaDurable GFLT 600S compound with excellent compression set
describe:Fluorine rubber has good high temperature resistance but poor low temperature resistance
Common grade resistors, GFLT600S are designed for low temperature conditions.
Material properties
| Raw rubber properties | |||||||
| grade | Mooney viscosity (1+10@121degree) | Gravity, g/cm3 | Fluorine content | compression deformation | Low temperature rebound | Volume change of CM-15 fuel | |
| GFLT 600S | 65 | 1.86 | 67 | 25 | -25 | 14 | |
Compound data sheet:
| Shift time: | 180 days | Material: | Viton compound | |||
| a lot of: | 20022201 | color: | Black | |||
| grade: | FL-A651 | quantity: | 100KG | |||
| Pressure curing: | 170℃@10 minutes | Post curing: | 230℃@24h | |||
| Room temperature: | 23°C | humidity: | 55% | |||
| Test items | Specification | Test Results | Test Methods | |||
| Typical Rheological Properties | ||||||
| Curing conditions: 177°C@600s | ||||||
| TS2: | 0:26 | minutes seconds | ASTM D1646 | |||
| TC10: | 0:29 | minutes seconds | ASTM D1646 | |||
| TC90: | 1:07 | minutes seconds | ASTM D1646 | |||
| ml: | 1.59 | cow rice | ASTM D1646 | |||
| male: | 21.67 | cow rice | ASTM D1646 | |||
| Typical Physical Properties | ||||||
| hardness | 66 | Shore A | ASTM D2240 | |||
| Tensile Strength | 13.95 | MPa | ASTM D412 | |||
| elongation at break | 286 | % | ASTM D412 | |||
| embrittlement temperature | -34 | degree | ASTM D746 | |||
| Comment: | This is to certify that the material specified above has been tested and complies with our QC specifications. | |||||
