"Patrol security robot" security robot autonomous outdoor security robot

PRODUCT DETAIL
Guidance method:Tape Guidance/Laser Guidance (Optional)Core component warranty:1 year
Moving speed:35m/minport:Shenzhen
Communication function:Serial port/WiFi (optional)Dimensions:L1400*W450*H250(mm)
Control Method:PLC/AGV mobile control chip (optional)Packaging Details:standard packaging.
Weight (kg):3000Carrying capacity:500KG
brand:you thinkWarranty:1 year
Marketing Type:2019 Hot ProductsShowroom location:United States
Core components:PLC, engine, bearing, gearPackage preview:
Driving power:DC24V, DC48VDrive mode:differential drive
Supply capacity:300 sets per monthpayment terms:Western Union, T/T, MoneyGram
Driving lift type:Manual or electric liftingplace of origin; place of origin:China
Applicable industries:Building material stores, machinery repair shops, manufacturing plants, food and beverage plants, restaurants, retail stores, print shops, construction, energy and mining, food and beverage stores, advertising agenciesMechanical test report:if
Direction of movement:Differential one-way or two-wayVideo shipment inspection:if



AGV type Two-way latent AGV
Dimensions L1400*W450*H250(mm)
way to control PLC/AGV mobile control chip (optional)
Guidance method Tape Guidance/Laser Guidance (Optional)
direction of movement Differential one-way or two-way
communication function Serial port/WiFi (optional)
drive mode differential drive
driving force DC24V, DC48V
driving lift Manual or electric lifting
Carrying capacity 500KG
Moving speed 35m/min
Turning radius Minimum 800mm (line paving radius)
Guidance accuracy ±10mm
job type 24 hours
Gradeability 2-3 degrees
stop accuracy ±10mm
charging type Manual charging (optional automatic charging)
Battery Maintenance-free battery, continuous discharge times>300 times
Safety sensing range ≤3m, adjustable 20mm emergency braking distance less than 20mm
human-computer interaction It adopts touch screen human-computer interaction, and it is convenient to set parameters, stations or alarms.
working environment Indoor temperature: 0-40 degrees Celsius; relative humidity: 40%-80%
Security Front obstacle detection sensor + mechanical anti-collision mechanism
Design life >10 years
