Portable Home Industrial Electric MMA Arc Welder DC Welder
- $23.00 / >=100 pieces
- 100 pieces
- Linyi Juheng Electromechanical Equipment Co., Ltd.
- Shandong, China
- Mr Liu
PRODUCT DETAIL
| Material/Metal Finishing: | Carbon steel, stainless steel, aluminum alloy | Warranty: | 1 year |
| payment terms: | L/C,Western Union,D/P,D/A,T/T,MoneyGram | Weight (kg): | 10.5kg |
| Packaging Details: | Cardboard box with foam. The color box is 100 pieces free of charge. | feature: | Inverter |
| port: | Qingdao | Supply capacity: | 10000 pieces per month |
| Applicable industries: | Building materials store, mechanical repair shop, construction works | maximum. Load power capacity: | 4.5KVA |
| Health status: | new | place of origin; place of origin: | China |
| Main selling point: | high productivity | Rated input voltage: | 220 volts |
| Output Polarity: | DC argon arc welding | Rated output voltage (TIG): | 50 volts |
| Rated Duty Cycle @40°C (TIG): | 60% |
Product Description
Model | WS/TIG-200 | WS/TIG-250 |
type | MOS 3 circuit board | MOS 3 circuit board |
AC input voltage (V) | AC 220V±15% | AC 220V±15% |
Rated input power capacity (KVA) | 6.6 | 7.5 |
Input frequency (Hz) | 50/60 | 50/60 |
No-load voltage (V) | 55 | 55 |
Output current range (A) | 20-200 | 20-250 |
Rated duty cycle (%) | 60% | 60% |
efficiency(%) | 85% | 85% |
Insulation class | F | F |
Enclosure rating | IP21 | IP21 |
Electrode diameter (mm) | 1.6-4.0 | 1.6-4.0 |
Welding thickness (mm) | 2-8 | 3-10 |
Quick connector size (mm) | 10-25 | 10-25 |
Net weight/GW(kg) | 6.0/10.5 | 7.0/11.5 |
Machine size (LxWxH mm) | 370*160*300 | 370*160*300 |
Packing size (LxWxH mm) | 470*270*430 color box + foam | 470*270*430 color box + foam |
Accessories | 1.8m 16mm 300A Bracket 1.2m 16mm 300A Clip wp-17 4m flashlight Mask, brush, instruction manual | 1.8m 16mm 300A Bracket 1.2m 16mm 300A Clip wp-17 4m flashlight Mask, brush, instruction manual |
