Wholesale Lever Chain Puller with Vital Japan Technology

PRODUCT DETAIL
Packaging Details:Standard export packagingchain:G80 chain
color:black, yellow, orange, white, blueChain painting:Galvanized or black coated
Package preview:Load chain:G80
Certificate:CE certificationLifting height:1.5M-3M
type:VLmodel:SBH-L type
capacity:0.8-6.4 tonsName:Lever block
Card:OEM productionplace of origin; place of origin:Hebei china
payment terms:L/C, T/T, MoneyGramport:Tianjin or Guangzhou
Supply capacity:10000 pieces per month
Product Description



Manual ratchet lever hoist/lever chain ratchet puller with TOYO Japanese technology





technical features

1. One-button operation to adjust the chain freely

2. Grade 80 alloy load chain ISO and GES standards

3. Forged and heat-treated hooks with batch traceability and tensile indicators

idling

1. Fully depress the retaining pawl and pull the grip ring towards you.

2. The chain can be adjusted up and down manually.

3. Terminate idling: Put the shift lever in the down position (see figure below). Then, depressing the pawl as far as it will go, gently push the clamp ring to engage the pawl with the outer edge of the stop plate. Next, grasp the grip ring and handle with one hand, and push them while turning them counterclockwise. The pawl returns to its original position.



* Specifications on this leaflet may be changed without notice for improvement.



Tested according to EN13157-2004

Product Code

capacity

(t)

standard elevator

(Meter)

test load

(t)

traction

(Kilogram)

pendant number

Lifting chain diameter

(mm)

Dimensions (mm)

net weight

(Kilogram)

One

Second

C

Ding

Second

HSH-A075

0.75

1.5

1.13

15

1

6.3

148

128

295

256

45

6.9

HSH-A100

1.00

1.5

1.50

20

1

6.3

152

128

310

256

48

7.0

HSH-A150

1.50

1.5

2.25

18

1

7.1

161

148

335

368

52

9.6

HSH-A200

2.00

1.5

3.00

twenty four

1

7.1

168

148

350

368

60

10.1

HSH-A300

3.00

1.5

4.50

38

1

9

191

180

405

368

66

15.9

HSH-A600

6.00

1.5

9.00

39

2

9

191

180

550

368

80

25.7

Separate validation load tests with separate serial numbers
