High Density 9995 Tungsten Foil Wolfram Strip Price
- $1.00 /kilogram
- 1 kilogram
- Shaanxi Getwick Metal Technologies Co., Ltd.
- Shaanxi, China
- Mr Alan Gao
| Place of Origin: | Shaanxi, China; | Supply Ability: | 5000 Kilograms per Month High Density 9995 Tungsten Foil Wolfram Strip Price; |
| Application: | Lighting; | Port: | Tianjin,Qingdao,Shanghai,Guangzhou,Shenzhen; |
| Density: | 19.3g/cm3; | Material: | 99.95%W; |
| Brand Name: | GETWICK; | Condition: | Annealing; |
| Payment Terms: | L/C,Western Union,D/P,D/A,T/T,MoneyGram,paypal; | Packaging Detail: | High Density 9995 Tungsten Foil Wolfram Strip Price; |
| Surface: | Caustic Washing; | Model Number: | W1 W2; |
| Product Name: | High Density 9995 Tungsten Foil Wolfram Strip Price; | Shape: | Plate Sheet Foil; |
| Purity: | 99.9% Min; | Certificate: | ISO9001:2008; |
| Technology: | hot rolling; |
High Density 9995Tungsten Foil Wolfram Strip Price
Grade: W1, W2, WAL1, WAL2, WAL3
Purity: W≥99.95%
Melting Point: 3410 DC
Boiling Point:5927 DC
Density: 18.5 - 19.3 g/cm3
Item: High Temperature Tungsten Foil
Application:
1.Used for sapphire single crystal growth furnace;
2. Applied for quartz glass melting furnace;
3. Used for rare earth smelting furnace;
4. Used for sintering metal mold of high melting point;
5. Widely used in other following industries:
Ceramics and metallurgical industries, machinery processing and light dustries.
Features:
1.Low thermal expansion;
2. High density;
3. Good corrosion resistance
4. High strength;
5. Low resistivity;
6.The surface roughness of tooled crucibles does not exceed Rz 6.3;
7.The use temperature below 2450ºC in vacuum or deoxidize atmosphere.
8.Manufactured based on customers' requirement.
Surface: shiny, alkaline washed, satin, or as-rolled condition; dependent upon thickness and width
parameters.
Normal specification we can provide:
|
Tungsten Plate/Sheet /Foil |
||
|
Thickness(min) mm |
Width(max) mm |
Length(max) mm |
|
0.05 |
150 |
500 |
|
0.06~0.09 |
250 |
500 |
|
0.1 |
300 |
500 |
|
0.12 |
320 |
550 |
|
0.15 |
350 |
600 |
|
0.2~0.6 |
400 |
600 |
|
0.7~0.9 |
400 |
800 |
|
1~2 |
450 |
800 |
|
2~10 |
450 |
600 |
|
10~15 |
450 |
500 |
|
15~25 |
300 |
500 |
We also provide other parameters of tungsten foils according to customers' requirements.t
