Widely used food grade coffee bean sugar coating machine
- $1100.00 /set
- 1 set
- Hangzhou Shengde Machinery Co., Ltd.
- Zhejiang, China
- Ms SED Machinery
PRODUCT DETAIL
| capacity: | 6-15kg/batch | Internal heating power: | 0.8 kW |
| Package preview: | weight: | 115 kg | |
| size: | 780*600*1360mm | Applicable industries: | Manufacturing Plants, Food & Beverage Plants, Farms, Food Stores, Energy & Mining, Food & Beverage Stores, Others |
| Main selling points: | easy to operate | Weight (kg): | 115 |
| Voltage: | 220V50Hz | Coating drum diameter (mm): | 400mm |
| Packaging Details: | wooden box | Mechanical test report: | Not available |
| place of origin; place of origin: | Zhejiang, China | Icing pan speed: | 0-40 rpm |
| Diameter of icing pan: | 600mm | Dimensions (L*W*H): | 780*600*1360mm |
| Marketing Type: | New Products 2020 | Blower motor power: | 100W |
| Coating Type: | heating and coating | Coating temperature (°C): | 1 - 80°C |
| Model: | SED-600BY-D | Total power: | 1700W |
| Showroom location: | not any | Core components: | PLC, engine, gearbox, motor, gear, pump |
| payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram | usage: | pharmaceutical |
| Video shipment inspection: | if | Power (kW): | 1.7 |
| State of health: | new | Warranty: | 1 year |
| brand: | SED-Pharmaceutical | Core component warranty: | 1 year |
| main motor power: | 0.75KW |
Product Description
This machine is mainly used for sugar coating of tablets, pills and granules, and is suitable for coating materials that cannot be sprayed and need to be added manually. This machine is widely used in pharmaceutical industry, candy manufacturing industry and food industry.
Working principle:
The sugar-coated tablet rolls and slides in the pot through the body of the pot, so that the sugar-coated powder is evenly distributed on all the medicines. An electric blower is included with the machine. The outlet pipe can be stretched into the cavity for heating. At the same time, use a hot air blower to blow to the inner layer of the pot to remove the moisture on the surface of the tablet to obtain hard sugar-coated tablets.
Model | 300BY-D | 400BY-D | 600BY-D | 800BY-D | 1000BY-D |
Diameter of icing pan(mm) | 300 | 400 | 600 | 800 | 1000 |
capacity(kg/batch) | 1-4 | 2-6 | 6-15 | 30-50 | 50-80 |
Internal heating power(kilowatt) | 0.5 | 0.5 | 0.8 | 0.9 | 0.9 |
icing pan speed(revolutions per minute) | 0-46 | 0-46 | 0-40 | 0-32 | 0-32 |
main motor power(kilowatt) | 0.12 | 0.12 | 0.75 | 1.1 | 1.1 |
Blower motor power(kilowatt) | 0.06 | 0.06 | 0.1 | 0.2 | 0.2 |
weight(Kilogram) | 30 | 35 | 115 | 230 | 240 |
total power(kilowatt) | 0.66 | 0.68 | 1.7 | 2.2 | 2.3 |
size(mm) | 560*300*850 | 560*400*850 | 780*600*1360 | 1150*800*1550 | 1150*1100*1600 |
