DPP-250 Automatic Medical Device Powder Blister Paper Packaging Machine
- $16000.00 / 1 - 1 sets
$15000.00 / >=2 sets - 1 set
- Ruian Furis Import & Export Co., Ltd.
- Zhejiang, China
- Mr Harold Zhang
PRODUCT DETAIL
| Video outbound inspection: | if | After Warranty Service: | Video technical support, online support, spare parts, on-site maintenance and repair services |
| Warranty: | 1 year | Showroom location: | Canada, UK, US, Germany, Saudi Arabia, Russia, Thailand |
| Health status: | new | Driver type: | electrical |
| port: | Ningbo Shanghai | Certification: | ISO9001 |
| Voltage: | 380V/50Hz 220V/60Hz | Marketing Type: | 2020 New Products |
| weight: | 1200 kg | Core component warranty: | 1 year |
| Core components: | PLC, bearings, motors, pressure vessels, gears, pumps | Automatic level: | automatic |
| Mechanical test report: | if | Dimensions (L*W*H): | 2900*750*1600mm |
| type: | Blister packaging machine | Origin: | Philosophy |
| Main selling points: | easy to operate | payment terms: | L/C, D/A, D/P, T/T, Western Union |
| Local service locations: | Canada, Turkey, United Kingdom, United States, Brazil, Indonesia, Russia, Thailand, Malaysia, Australia, Colombia | application: | beverage, medical |
| Applicable industries: | Manufacturing plants, machinery repair shops, restaurants, home use | Supply capacity: | 1 set per month |
Product Description
Specification
Model Model | DPP-250A |
Punching times punching frequency | 15-45 times/min 15-45 times/min |
Maximum forming area and depth maximum. Forming area and depth | 250x120 (standard depth ≤ 15mm) maximum depth 30mm (customized) Maximum 250x120 (standard depth ≤ 15mm) depth 30mm (after adjustment |
Standard travel range Standard travel range | 30-130 mm (can be designed according to customer requirements) 30-130mm (can be designed according to user requirements) |
standard section Standard board size | (can be designed according to customer requirements) (can be designed according to user requirements) |
air pressure air pressure | 0.6-0.8 MPa 0.6-0.8Mpa |
total power main switch | 380V 50Hz 8kW |
PVC hard sheet PVC hard film | 0.15-0.4*260 mm (mm) 0.15-0.4*260 (mm) |
PTP aluminum foil PTP aluminum film | 0.02-0.015*260 mm (mm) 0.02-0.015*260 (mm) |
cheap paper Dialysis paper | 50-100g*260mm (mm) 50-100g*260 (mm) |
mold cooling mold cooling | Tap water or circulating water Tap water or circulating water |
Dimensions Dimensions | 3900*750*1600mm Dimensions (including feet) 1500*750*1600mm split size (front) 1400*750*1450mm split size (rear) |
weight weight | 1200 kg 1200 kg |
