UT61E Digital Multimeter 6000 Counts Autoranging AC/DC Voltmeter Tester
- $1.00 / >=10 units
- 10 units
- Chongqing Huakong Technology Co., Ltd.
- Guangdong, China
- Ms elena he
PRODUCT DETAIL
model: | UT61E | Supply capacity: | 10000 pieces per month |
product name: | UT61E Modern Digital Multimeter | brand: | unit |
port: | Shenzhen | Origin: | China |
payment terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Product Description
UT61 series comply with CE, ETL, GS standards. This series is all auto-ranging
Optional true rms model (UT61D/E). The series is rich in features combined with a high safety rating of CAT IV
600 volts. It is intended for advanced electronics and electrical users.
1. Auto range
2. MAX/MIN/REL mode
3. RS-232 and USB interface
4. Simulate a bar chart
5. Low battery indication
6. True RMS
7. Peak/hold
8. Diode/on-off buzzer
8. Data retention
9. Input protection
Optional true rms model (UT61D/E). The series is rich in features combined with a high safety rating of CAT IV
600 volts. It is intended for advanced electronics and electrical users.
1. Auto range
2. MAX/MIN/REL mode
3. RS-232 and USB interface
4. Simulate a bar chart
5. Low battery indication
6. True RMS
7. Peak/hold
8. Diode/on-off buzzer
8. Data retention
9. Input protection
Specification
Specification | scope | UT61A | UT61B | UT61C | UT61D | UT61E | ||||||
DC voltage (V) | 1000V | ±(0.5%+1) | ±(0.5%+1) | ±(0.5%+1) | ±(0.5%+1) | ±(0.1%+2) | ||||||
AC voltage (V) | 750V | ±(1%+3) | ±(1%+3) | ±(1%+3) | ±(1%+3) | ±(0.8%+10) | ||||||
DC current (A) | 10A | ±(1%+2) | ±(1%+2) | ±(1%+3) | ±(1%+3) | ±(0.5%+10) | ||||||
AC current (A) | 10A | ±(1.2%+5) | ±(1.2%+5) | ±(1.2%+5) | ±(1.2%+5) | ±(0.8%+10) | ||||||
Resistance (Ω) | 40MΩ | ±(1%+2) | ±(1%+2) | |||||||||
60MΩ | ±(1%+2) | ±(1%+2) | ||||||||||
220MΩ | ±(0.5%+10) | |||||||||||
Capacitance (F) | 4000 microfarads | ±(3%+5) | ±(3%+5) | ±(3%+5) | ±(3%+5) | |||||||
220 millifarad | ±(3%+5) | |||||||||||
Frequency (Hz) | 10Hz~10MHz | ±(0.1%+4) | ±(0.1%+4) | ±(0.1%+4) | ±(0.1%+4) | |||||||
10Hz~220MHz | ±(0.01%+5) | |||||||||||
temperature | -40℃~1000℃ | ±(1.2%+3) | ±(1.2%+3) | |||||||||
-40°F~1832°F | ±(1.2%+4) | ±(1.2%+4) | ||||||||||
feature | ||||||||||||
Display times | 4000 | 4000 | 6000 | 6000 | 22000 | |||||||
Bandwidth (Hz) | 45Hz~400Hz | 45Hz~400Hz | 45Hz~1kHz | 45Hz~3kHz | 45Hz~10kHz | |||||||
duty cycle | 0.1%~99.9% | √ | √ | √ | √ | √ | ||||||
general characteristics | ||||||||||||
strength | 9V battery (6F22) | |||||||||||
exhibit | 65 mm x 43 mm | |||||||||||
Product color | red and gray | |||||||||||
Product Weight | 370 grams | |||||||||||
Product Size | 180mm x 87mm x 47mm | |||||||||||
Standard accessories | Battery, test leads, multi-purpose socket, RS-232 interface cable (UT61B/UT61C/UT61D/UT61E), host computer software CD (UT61B/UT61C/UT61D/UT61E), point contact temperature probe (UT61B/UT61C) | |||||||||||
Standard Individual Packaging | Gift box, English manual | |||||||||||
Standard quantity per box | 22 | |||||||||||
Standard carton size | 455mm x 335mm x 375mm | |||||||||||
Standard carton gross weight | UT61A: 12.7kg; UT61B: 13.97kg; UT61C: 13kg; UT61D: 14.5kg; UT61E: 12.9kg | |||||||||||
optional accessories | UT61B/UT61C/UT61D/UT61E: USB interface cable |
