Dairy Factory Complete factory for processing milk and pasteurized milk drinks

PRODUCT DETAIL
Supply capacity:10 units per monthAfter-sales service provided:Video Technical Support
Video shipment inspection:ifbrand:Qing Kee
Marketing Type:New Products 2020Sterilization time:15-30 seconds (customized)
Processing type:milkplace of origin; place of origin:China Shanghai
pressure:0.6MPaMechanical test report:if
Material:SUS304/SUS316Packaging Details:International standard packing or your request
After warranty service:Video technical support, online support, on-site maintenance and repair servicesHeating area:3m2
Steam consumption:70kg/hourcapacity:500L
Local service location:not anyShowroom location:not any
Processing:SterilizerSterilization temperature:85°C
Dimensions (L*W*H):3000X2000X2700mmVoltage:380V or customized
weight:1300 kgApplicable industries:Food and Beverage Factory
port:Shanghai/Ningbomodel:BTG-UHT-0.5MJ
State of health:newstrength:9.5kw
Warranty:1 yearproduct name:Dairy Plant Complete Pasteurized Milk and Beverage Processing Plant
structure:plateusage:pasteurized milk
Core component warranty:1 yearCore components:PLC, water pump
payment terms:L/C, Western Union, T/T, MoneyGram, PayPalCertification:EU/ISO
Product Description
product name
Shanghai Qingji 500L/H Small Tube UHT Milk Beverage Sterilizer
Designing ability
500 liters/hour
total power
9.5KW
heating zone
3m2
size
3000×2000×2700mm
pipeline pressure
5 MPa
weight
1300 kg
Sterilizer temperature
140°C
Sterilization time
5 to 300S
cooling water pressure
0.3MPa
Cooling water temperature
≤20℃
ice water consumption
3 tons/hour
steam consumption
70kg/hour
Barrel
φ16×1.5mm
water pipe
φ25×1.5mm
steam pipe
φ50.8×1.5mm
Air compressor tube
φ50.8×1.5mm
Capacity can also be selected: 1000L/H, 2000L/H, 3000L/H, 5000L/H, 8000L/H, 10000L/H
detailed drawing
