hydraulic rock splitter
- $5000.00 /set
- 1 set
- Xiamen Bestlink Factory Co., Ltd.
- Fujian, China
- Mr Richard Chen
| payment terms: | L/C, Western Union, D/P, D/A, T/T | brand: | Bailian |
| Key words: | Diesel Driven Hydraulic Rock Splitter | Weight (kg): | 260 |
| Warranty: | 1 year | Marketing Type: | New Products 2020 |
| Video shipment inspection: | if | Showroom location: | not any |
| color: | blue, green, yellow | Applicable industries: | Building material stores, manufacturing plants, machinery repair shops, construction projects |
| port: | Xiamen | Packaging Details: | Wooden case or according to your specific requirements |
| Mechanical test report: | if | usage: | For quarrying and civil construction |
| Core component warranty: | Not available | Motor type: | DC |
| place of origin; place of origin: | Fujian China | Supply capacity: | 20000 sets per month |
| Core components: | engine | Certification: | CE certification |
| Dimensions (L*W*H): | 1150*1180*940mm | Types of: | stone crusher |
| State of health: | new | application: | for stone quarrying |
Rock and Concrete Separators
It is a new quarrying and civil construction product developed by our company, mainly suitable for the secondary crushing of boulders, the square crushing of boulders, and the cubes. Drive motor: electric/diesel/gasoline/pneumatic.
BS36/38/40 adopts iron cylinder, BS42/45 has iron cylinder and aluminum alloy cylinder. Aluminum alloy cylinders are lighter and stronger. In addition, we have successfully copied the same type of cylinder from Darda in Germany, the model is . It is C12(N), which has the same shape, parts and performance as the original car.
feature:
1) Huge splitting force up to 410 tons
2) Dust-free and nearly silent operation
3) No vibration
4) Light weight
5) Precision work
6) Always in control
7) For close and inaccessible places.
8) Easy handling
Specification:
1. Hydraulic pump set
| A) Electric motor drive type | |||||||
| Power model | Dimensions (mm) | Weight (kg) | Oil pump station reserves (L) | engine power | Working pressure (MPa) | Flux (l/m) | Splitter can be towed quantity (pc) |
| electric motor | twenty three | 5 | 0.75KW (220V/380V) | 55-60 | 0.7 | 1 | |
| 384*280*620 | 75 | 30 | 3KW(380V) | 55-60 | 2 | 1-3 | |
| 7.5KW (380V) | 55-60 | 13 | 1-10 | ||||
| B) Gasoline engine drive model | |||||||
| Power model | Dimensions (mm) | Weight (kg) | Oil pump station reserves (L) | engine power | Working pressure (MPa) | Flux (L/m) | Splitter can be towed quantity (pc) |
| Gasoline | 1200*1170*800 | 100 | 40 | 7.5 hp | 55-60 | 2-13 | 1-10 |
| C) Diesel drive model | |||||||
| Power model | Dimensions (mm) | Weight (kg) | Oil pump station reserves (L) | engine power | Working pressure (MPa) | Flux (L/m) | Splitter can be towed quantity (pc) |
| Diesel engines | 1150*1180*940 | 260 | 40 | 5.15KW | 55-60 | 2-13 | 1-10 |
| D) Pneumatic drive type | |||||||
| Power model | Dimensions (mm) | Weight (kg) | Oil pump station reserves (L) | Rated power (kw) | Working pressure (MPa) | Oil flux (L/m) | Splitter can be towed quantity (pc) |
| air motor | 384*280*620 | 70 | 30 | 4.10 | 55-60 | 2-13 | 1-10 |
2. Hydraulic cylinder:
| required aperture | Drilling depth requirement in minutes | split distance | split time | theoretical division force | Actual split power | cylinder weight |
| 32-35mm | 300mm | 10-30mm | 5-12s | 380 tons | 220 tons | 20 kg |
| 35-38mm | 400mm | 10-35mm | 5-12s | 560 tons | 310-320 tons | 25 kg |
| 38-42mm | 500mm | 10-40mm | 5-12s | 680 tons | 410-120 tons | 32 kg |
